Our Products



SILO

Shop-Weld Construction
Applications: Liquids, plastic resins, food products, dry chemicals,minerals, wood waste & misc. dry other-Hopper capacities under 10,000 cubic feet- Liquid storage up to 80,000 gallons-Shop-controlled quality-One piece tank construction- Factory applied coating systems-Increased freight cost to the jobsite-Less field installation requirements
Bolted Smoothwall RTP (rolled, tapered panel) Construction
Applications: Water, wastewater, fire protection, cement, fly ash,coal, limestone, lime, aggregates, minerals, chemicals, plastics, select foods, wood waste & misc. dry other- Hopper capacities from1000 –100,000 cubic feet-Liquid storage up to 8.2 million gallons- Shop-controlled quality-Modular construction requires bolted field assembly- Decreased field installation timeframe-Factory applied powder coating systems
Field-Weld Construction
Applications: Water, wastewater, industrial liquids, minerals, aggregates, dry chemicals & misc. dry other-Hopper capacities from 20,000 –250,000 cubic feet-Liquid storage up to 25 million gallons-Shop-controlled quality –minimize large piece count-Modular construction requires field welded assembly-Increased field installation timeframe-Field applied coating systems
In general, storage applications that require a storage volume of less than 10,000 cubic feet (dry) or 30,000 gallons (liquid)will utilize a shop-welded or smooth wall bolted tank. Both products are used interchangeably in the industry. Shop-weld and bolted construction maintain advantages as listed above. Under review, the total installed costs (material + freight + field installation) are comparable between both products. Bolted RTP (rolled, tapered panel), field-weld, concrete and hybrid tanks are typically utilized in large volume storage applications. All four designs are routinely specified in the power industry. In the industrial market, bolted RTP and hybrid construction are the most cost efficient silo designs. Field-weld and concrete construction require extended field installation timeframes, which equates to higher installed cost. Relative to “materials of construction” selection, bolted, shop-weld and field-weld silos are available in coated carbon steel, stainless steel and aluminum construction. All tanks/silos are customized for the application and are available for installation at grade level or elevated. Typical tank accessories include man way accesses, level control nozzles, maintenance access platforms, agitators, heaters, insulation, caged ladders, spiral stairways, perimeter guardrails, and custom requirements for system integration
